Product Details:
Place of Origin: CHINA
Brand Name: HANJIU
Certification: CE
Model Number: BMP BMR BMH BMS BMT BMV
Payment & Shipping Terms:
Minimum Order Quantity: 100 Sets
Price: 41 usd - 100 usd
Packaging Details: 27x40x15cm
Delivery Time: 25 - 35 work days
Payment Terms: T/T, Western Union, D/P
Supply Ability: 200000 sets per year
Detailed Product Description
Item: High Torque Low Speed Motor Model: Eaton Parker Danfoss White Replace
Size: 8cc To 1000cc Brand: Hanjiu
High Light:

slow speed high torque motor

,

lsht hydraulic motor

Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality or OEM Replacement



Hydraulic Motors

Hanjiu has a complete selection of hydraulic motors to fill your requirements. Low speed high torque motors from Hanjiu Technology, 2 bolt, 4 bolt and wheel drive versions are standard. Keyed or spline shafts are standard as are SAE or NPT ports and displacements from .78cc to 524cc. directly interchangeable with the leading industry brands.



Hanjiu Manufacturing offers original quality or OEM replacement motor for Eaton, Parker, Danfoss, White, Ross, TRW, Brivini

Hanjiu motors with the following Features and benefits include:

  • Robust construction for longer life
  • Continuous oil flow across internal splines for longer life
  • Superior side load capacity
  • Smooth, extra low speed operation
  • High pressure shaft seal as standard
  • Innovative design eliminates the need for a drain
  • Roller vanes and sealed commutator maintain high efficiency
  • and provide smooth low speed performance.





Low speed high torque motor :

Low speed high torque hydraulic motor are rotary actuators that convert hydraulic, or fluid energy into mechanical power. They work in tandem with a hydraulic pump, which converts mechanical power into fluid, or hydraulic power. Hydraulic motors provide the force and supply the motion to move an external load.



Take BMER are example:



type

BMER

125

BMER

160

BMER

200

BMER

230

BMER

250

BMER

300

BMER

350

BMER

375

BMER

400

BMER

475

BMER

540

BMER

650

BMER

750

Max. speed (rpm) cont. 360 375 330 290 290 250 220 200 185 160 140 115 100
int. 490 470 425 365 350 315 270 240 220 195 170 138 120
Max. torque (N•m) cont. 325 450 530 625 700 810 905 990 1010 1085 980 1015 1050
int. 380 525 600 710 790 930 1035 1140 1180 1180 1240 1250 1180
peak 450 590 750 870 980 1120 1285 1360 1360 1260 1380 1380 1370
Max. output (kW) cont. 12 15 15.5 16 17.5 18 17.5 16.5 15.5 14.5 11.5 10 8
int. 14 17.5 18 19 20 21 20 19 18 16.5 15 12 10
Max. pressur drop e (MPa) cont. 20.5 20.5 20.5 20.5 20.5 20.5 20. 5 20.5 19 17.5 14 12 10.5
int. 24 24 24 24 24 24 24 24 22.5 19 17.5 15.5 12
peak 27.6 27.6 27.6 27.6 27.6 27.6 27.6 27.6 25 20.5 20.5 17.5 14
Max. flow (L/min) cont. 45 60 70 70 75 80 80 75 75 75 75 75 75
int. 60 75 85 85 90 95 95 90 90 90 90 90 90





Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 0



Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 1


Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 2



Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 3




Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 4


Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 5


Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 6


Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 7


Fluid Power Solution Hydrulic Motor Orbital Motors Original Quality Or OEM Replacement 8






Hydraulic Motors

If you don’t see what you are looking for on this page or need assistance with choosing a hydraulic motor for your application please contact us Here! We will be happy to help assist you with sizing and application of a hydraulic motor for your application.
