Product Details:
Payment & Shipping Terms:
|
| Product: | Orbital Motor | Type: | Oil Motor |
|---|---|---|---|
| Feature: | Danfoss Equivalent | OEM: | 151B3101 |
| Displacement: | 400 Ml/r | Flange: | 4 Hole |
| Ports: | G1 - G1/4 | Shaft: | Cylindrical 50mm |
| High Light: | oil Orbital Motor,151B3101 |
||
Code: 151B3101
Aftermarket code: BMV-400
Basic Motor: OMV
Displacement: 400
Mounting Flange: Standard
Shaft Style: Cylindrical
Shaft Size: 50 mm ; M12 x 1,75 tap
Shaft Key: A14 x 9 x 70 mm (DIN 6885)
Port Size: Side port
Port Dimension: G 1
Drain Port Style: Standard
Drain port Dimension: G 1/4
| Danfoss Number | Disp. | Shaft | Keyway | Port | Drain |
| 151B3101 | 400 | 50mm | A14X9X70 | G1 | G1/4 |
| Unit weight | 32.6kg |
| Packing size | 44 x 24 x 22cm |
| Maximum Continuous Output Speed | 500 rpm |
| Maximum Intermittent Output Speed | 600 rpm |
| Maximum Continuous Output Torque | 1180Nm |
| Maximum Intermittent Output Torque | 1410Nm |
Danfoss similar type motors are available we belows:
Most complete range of Danfoss OMM, OMP, OMR, OMH, OMS, OMT, OMV series aftermarket motors
Applications: Mowing, snow removal, sprayer, trencher and wood products
sometimes Item is in stock, sometimes not, when there is no a stock it needs 25 days to produce new
