Orbital Steering Units 150L2084 OSPM 50 ON For Road Sweepers Turf Care Machinery And Tractors

Large Image : Orbital Steering Units 150L2084 OSPM 50 ON For Road Sweepers Turf Care Machinery And Tractors

Product Details:

Place of Origin:	China
Brand Name:	HANJIU
Certification:	CE
Model Number:	150L2084

Payment & Shipping Terms:

Minimum Order Quantity:	1 Pieces
Price:	Contact seller to ask
Packaging Details:	Box, Pallet
Delivery Time:	35 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union
Supply Ability:	10000 pieces per year

Contact Now

Detailed Product Description

Item:	Steering Unit	Type:	Hydraulic
Direction:	Left And Right	OEM #:	OSPM 50 ON
Displacement:	8cc - 50cc	Function:	Open Center Non-reaction
Highlight:	cycloid hydraulic motor , hydraulic rotary motor

Orbital Steering Units 150L2084 OSPM 50 ON for road sweepers, turf care machinery and tractors

This is a replacement steering units for Danfoss OSPM Steering

OEM #: 150L2084, OSPM 50 ON

Aftermarket #: 109-50

The 109 hydraulic steering unit is available in: open-centre non-reaction.

It is particularly suited to road sweepers, turf care machinery and lawan tractors.

Features of 109 steering units include:

Good steering control
Low steering torque 1.2 to 2.0 N
One or several built in valve functions possible: shock in L + R, pressure relief valve and check valve in P and LS
Maximum steering pressure 150 bar (P-T).

Main Specification

Parameters	Type 109-1---*
Displacement(mL/r)	20	32	40	50	63	80
Rated flow(L/min)	3~20
Rated Pressure(MPa)	12.5
Relief Valve Pressure Settings(MPa)	06,07,08,09,10
Shock Valves Pressure Settings(MPa)	12,13,14,15,16
Steering Torque(N·m)	≤1.8
Max．Cont．Preesure in Line T-PT(MPa)	1
Dimension L(mm)	87	92	96	100	105	113

We provide many type steering unit to replace Danfoss OSPM :

Code	No.
OSPM 32 ON	150L2103
OSPM 32 ON	150L2104
OSPM 40 ON	150L2079
OSPM 50 ON	150L0111
OSPM 50 ON	150L0112
OSPM 50 ON	150L0133
OSPM 50 ON	150L2113
OSPM 50 ON	150L2114
OSPM 50 ON	150L2150
OSPM 50 ON	150L2132
OSPM 63 ON	150L0142
OSPM 63 ON	150L0143
OSPM 63 ON	150L0144
OSPM 80 ON	150L0121
OSPM 80 ON	150L0122
OSPM 80 ON	150L0137
OSPM 80 ON	150L2123
OSPM 80 ON	150L2124
OSPM 80 ON	150L2136
OSPM 100 ON	150L0154
OSPM 100 ON	150L0155
OSPM 100 ON	150L0156

Orbital Steering Units 150L2084 OSPM 50 ON For Road Sweepers Turf Care Machinery And Tractors 0

We also provide many more other type steering units to replace Danfoss OSPB, OSPC

Orbital Steering Units 150L2084 OSPM 50 ON For Road Sweepers Turf Care Machinery And Tractors 1
