Product Details:
Payment & Shipping Terms:
|
| Model No.: | 3P80 | Warranty: | 12-18 Months |
|---|---|---|---|
| Spool: | 1, 2, 3, 4, 5, 6, ... | Flow: | 40lt, 50lt, 60lt, 80lt, 100lt, 120lt, 140lt, ... |
| Function: | O/Y/P/A | Replacement: | Badestnost/walviol |
| High Light: | agricultural machines directional control valve hydraulic,3 levers directional control valve hydraulic,21gpm hydraulic directional control valve |
||
Product details:
| Ambient temperature | -40C...+60C |
| Viscosity | 12 ...800 mm2/s |
| Fluid temperature | -15C...+80C |
| Filtration | 10 to NAS 1638 |
| Max operating pressure | 315 bar |
| Back pressure | 50 bar |
| Nominal flow | 80 l/min |
| Leakage(A,B-T) | 15cm3/min at 120bar |
| Spool stroke | +/-7 mm |
| Actuating force | < 200 N |
| Modification/ Spools | 3spools |
Agricultural machines were made for heavy work, however, one cannot think of a good operation without a hydraulic control with the high quality circuit and an excellent installation. The system is responsible for driving the oil flow to the various actuators, thus allowing the energy generated in the hydraulic pump to be taken to the engines and cylinders.
There is a wide variety of hydraulic controls available on the market, in different sizes for different flows and pressures. Hydraulic controls are not for the exclusive use of agricultural machines and tractors. Because these oil-hydraulic systems can also be used in stationary hydraulics, mobile hydraulics, industrial machines, forklifts, drills, cranes, among others.
Furthermore, the functionality of the hydraulic command is the same in each of these equipment, regardless of the applicability, since it serves to allow the control of valve movements, being manually, electrically or pneumatically connected.
HYDRAULIC CONTROLS, THE ADVANTAGES OF USING
There are countless advantages that hydraulic controls bring to your machines or equipment.
Today, due to high technology, the hydraulic controls have on-board electronic components that guarantee the quality of the processing and distribution of hydraulic power.
Another point that should be highlighted is that the command has overload protection, as it has an oil pressure limiter in its system through the safety valve, thus avoiding accidents.
Agricultural Machines – Tractors, Harvesters, Sprayers and Planters;
Logistics – Platform Trucks, Cranes, Muncks, Forklift Garbage Collectors;
