Tf Series Lsht Orbit Hydraulic Motor 1 1/4" Keyed Magneto Mounting 334 Rpm

Tf Series Lsht Orbit Hydraulic Motor 1 1/4" Keyed Magneto Mounting 334 Rpm
Tf Series Lsht Orbit Hydraulic Motor 1 1/4" Keyed Magneto Mounting 334 Rpm Tf Series Lsht Orbit Hydraulic Motor 1 1/4" Keyed Magneto Mounting 334 Rpm Tf Series Lsht Orbit Hydraulic Motor 1 1/4" Keyed Magneto Mounting 334 Rpm Tf Series Lsht Orbit Hydraulic Motor 1 1/4" Keyed Magneto Mounting 334 Rpm

Large Image :  Tf Series Lsht Orbit Hydraulic Motor 1 1/4" Keyed Magneto Mounting 334 Rpm

Product Details:
Place of Origin: China
Brand Name: HANJIU
Certification: CE
Model Number: TF0280MS030AAAA
Payment & Shipping Terms:
Minimum Order Quantity: 100 Pieces
Price: Contact the seller to get a quote
Packaging Details: Box, Pallet
Delivery Time: 55 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 10000 pieces per year
Detailed Product Description
Item: Torqmotor OEM #: TF0280MS030AAAA
Manufacturer: Hanjiu Displacement: 280 Ml/r
Mounting Flange: 4-hole Shaft Type: Key Shaft
High Light:

tf series orbit hydraulic motor

,

lsht orbit hydraulic motor

,

334 rpm motor orbit hydraulic

TF Series LSHT Motor, 1 1/4" Keyed, Magneto Mounting, Maximum Speed 334 RPM



Quick review:

TF0280MS030AAAA Parker compatible low speed, high torque hydraulic motor. 19.20 cu. in. / rev displacement. Maximum pressure 1766 PSI continuous. Torque 4956 in-lb. continuous. Maximum speed 240 RPM continuous. Flow rate 34.0 GPM. 1 1/4" diameter shaft with keyway. 7/8-14 SAE ports. Magneto mounting flange. 1 year warranty



Sturdy construction throughout makes TF Series motors suitable for the most severe applications. All splines are constantly flushed with cool fluid for durability. Roller vanes and sealed commutation assure high volumetric efficiency, smooth low speed operation and extended life. Shaft seals can withstand full system pressure and are washed in cool fluid for long life.



Small Frame Low Speed, High Torque Motor
Manufacturer: Hanjiu



Details specifications



Series:  TF
Shaft: Key shaft
Rotation: Clockwise rotation
Displacement (cm3/rev): 19.20 cu. in. / rev
Mounting: 4 Bolt
Maximum speed: 240 RPM continuous





More Parker type Torque motors:

TB, TC, TJ, TE, TF, TG, TK
