BMS BMSY BMSYS OMSS Bearingless Short Motor 125CC For Agri Harvester And Mining Equipment

Large Image : BMS BMSY BMSYS OMSS Bearingless Short Motor 125CC For Agri Harvester And Mining Equipment

Product Details:

Place of Origin:	China
Brand Name:	Hanjiu
Certification:	ISO9001
Model Number:	BMSYS-125-D-D-B

Payment & Shipping Terms:

Minimum Order Quantity:	100 Pieces
Price:	Contact the selle to get the best offer
Packaging Details:	Standard export package
Delivery Time:	0 - 30 working days
Payment Terms:	T/T
Supply Ability:	100,000 units / Year

Contact Now

Detailed Product Description

Item:

Orbit Hydraulic Motor

Model No.:

BMSYS-125-D-D-B

Displacement:

125 Ml/r

Flange:

4 Bolt

Highlight:

125CC Bearingless Short Motor

Mining Equipment Bearingless Short Motor

Agri Harvester Bearingless Short Motor

Quick Review:

BMSY Series Orbit Hydraulic Motors, BEARINGLESS, 125ml/r, 4 bolt mounting, short shaft, G1/2 port

Features:

This motor can replace Danfoss OMS, M+S MS, Eaton Charlynn 2000 series

Shaft: splined 12 teeth 12/24 Pitch Ø27.6mm
Flange: short 4 holes Ø125mm Ø99.9m centring
Ports: 1/2 BSP (A & B) 1/4 BSP (D)
Compatible with 151F0538

Specification:

Main Specifications:

Type		BMSY BMSE 80	BMSY BMSE 100	BMSY BMSE 125	BMSY BMSE 160	BMSY BMSE 200	BMSY BMSE 250	BMSY BMSE 315	BMSY BMSE 375
Geometric displacement (cm3 /rev.)		80.6	100.8	125	157.2	200	252	314.5	370
Max. speed (rpm)	cont.	800	748	600	470	375	300	240	200
Max. speed (rpm)	int.	988	900	720	560	450	360	280	240
Max. torque (N·m)	cont.	190	240	310	316	400	450	560	536
	int.	240	300	370	430	466	540	658	645
	peak	260	320	400	472	650	690	740	751
Max. output (kW)	cont.	15.9	18.8	19.5	15.6	15.7	14.1	14.1	11.8
Max. output (kW)	int.	20.1	23.5	23.2	21.2	18.3	17	18.9	17
Max. pressure drop (MPa)	cont.	17.5	17.5	17.5	15	14	12.5	12	10
	int.	21	21	21	21	16	16	14	12
	peak	22.5	22.5	22.5	22.5	22.5	20	18.5	14
Max. flow (L/min)	cont.	65	75	75	75	75	75	75	75
Max. flow (L/min)	int.	80	90	90	90	90	90	90	90
Max. inlet pressure (MPa)	cont.	25	25	25	25	25	25	25	25
Max. inlet pressure (MPa)	int.	30	30	30	30	30	30	30	30
Weight (kg)		9.8	10	10.3	10.7	11.1	11.6	12.3	12.6

* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.

BMS BMSY BMSYS OMSS Bearingless Short Motor 125CC For Agri Harvester And Mining Equipment 0

BMS BMSY BMSYS OMSS Bearingless Short Motor 125CC For Agri Harvester And Mining Equipment 1

BMS BMSY BMSYS OMSS Bearingless Short Motor 125CC For Agri Harvester And Mining Equipment 2

More Hydraulic Orbital Motor available:

BMS BMSY BMSYS OMSS Bearingless Short Motor 125CC For Agri Harvester And Mining Equipment 3

About Hanjiu:

From China, HANJIU technology design, develop and manufacture hydraulic orbital motors. Shipped to all over the world, customers use our hydraulic motors directly as compatible motors for Danfoss, M+S, Eaton, Parker, White, Dana Brevini. Obtain the maximum benefit with the minimum cost, and you have no risk in cooperating with us. If you are hydraulic motor importer, wholesaler, OEM factory, contact us to discuss cooperation and get big customer discount.
