Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors

Large Image : Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors

Product Details:

Place of Origin:	CHINA
Brand Name:	HANJIU
Certification:	CE
Model Number:	101S-5T-500-15-E

Payment & Shipping Terms:

Minimum Order Quantity:	50 Sets
Price:	Negotiable
Packaging Details:	Carton Packing and finally with a Tray, or Wooden Box
Delivery Time:	10-15 work days
Payment Terms:	L/C,T/T
Supply Ability:	300000 Sets Per Year

Contact Now

Detailed Product Description

Product Name:	Tractor Spare Parts	Relieve Valve:	15Mpa
Shock Valve:	21Mpa	Function:	Load Sensing
Displacement:	500 Ml/r	Max Input Speed:	75rpm
Highlight:	Hydrostatic steering unit for tractors , Load sensing orbital steering valve , HKUS500/5T tractor steering unit

Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors

type number:Hanjiu 101S-5T-500-15-E

displacement:500cc

function:load sensing type

relief valve pressure settings:15mpa

shock valve pressure settings:21mpa

crossing code:OSPC500 LS,HKUS500/5T

Specification:

Parameters	Series 101S-5(T)(TE)(L)(E)-***
Displacement (mL/r)	50	63	80	100	125	160	200	250	280	315	400	500
Max.input speed(rpm)	100								75
Max.input pressure(Mpa)	17.5
Max.cont.back pressure	2.5
Relief Valve Pressure Settings(Mpa)	06,07,08,10,12,14,15,16.5,17.5
Shock Valves Pressure Settings(Mpa)	12,13,14,16,18,20,21,22,23.5
Weight(kg)	5.75	5.81	5.89	5.93	6.1	6.3	6.5	6.73	6.91	7.1	7.5	8.3
Dimension L (mm)	130	132	134	137	140	145	150	156	161	166	176	183

Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors 0

Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors 1

Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors 2

Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors 3

Hydrostatic Steering Unit HKUS500/5T load sensing orbitrol for tractors 4
