Product Details:
Payment & Shipping Terms:
|
| Product Name: | Hydraulic Orbital Motors | Displacement: | 36cc,50cc,80cc,100cc,125cc,160cc......500cc |
|---|---|---|---|
| Applications: | Agricultural Machine, Lifting Equipment | Replacement: | Eaton S,T Series |
| Oil Temperature: | Normal-35℃-80℃ | Shaft: | Cylindrical Shaft φ25.4mm,woodruff Key |
| High Light: | fluid low speed high torque hydraulic motor,charlynn low speed high torque hydraulic motor,ts series charlynn hydraulic motor |
||
Fluid Solution hydraulic speed sensor Lsht Motor 15.85GPM square 4-Bolts Mount 1" charlynn T.S series motor
Main Specifications:
Technical data for BMR with 25 and 1 in and 1 in splined and 28.56 tapered shaft:
| Type | BMR BMRS 36 |
BMR BMRS 50 |
BMR BMRS 80 |
BMR BMRS 100 |
BMR BMRS 125 |
BMR BMRS 160 |
BMR BMRS 200 |
BMR BMRS 250 |
BMR BMRS 315 |
BMR BMRS 375 |
|
| Geometric displacement (cm3 /rev.) | 36 | 51.7 | 81.5 | 102 | 127.2 | 157.2 | 194.5 | 253.3 | 317.5 | 381.4 | |
| Max. speed (rpm) | cont. | 1085 | 960 | 750 | 600 | 475 | 378 | 310 | 240 | 190 | 155 |
| int. | 1220 | 1150 | 940 | 750 | 600 | 475 | 385 | 300 | 240 | 190 | |
| Max. torque (N·m) | cont. | 72 | 100 | 195 | 240 | 300 | 360 | 360 | 390 | 390 | 365 |
| int. | 83 | 126 | 220 | 280 | 340 | 430 | 440 | 490 | 535 | 495 | |
| peak | 105 | 165 | 270 | 320 | 370 | 460 | 560 | 640 | 650 | 680 | |
| Max. output (kW) | cont. | 8.5 | 9.5 | 12.5 | 13 | 12.5 | 12.5 | 10 | 7 | 6 | 5 |
| int. | 9.8 | 11.2 | 15 | 15 | 14.5 | 14 | 13 | 9.5 | 9 | 8 | |
| Max. pressure drop (MPa) | cont. | 14 | 14 | 17.5 | 17.5 | 17.5 | 16.5 | 13 | 11 | 9 | 7 |
| int. | 16.5 | 17.5 | 20 | 20 | 20 | 20 | 17.5 | 15 | 13 | 10 | |
| peak | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 20 | 17.5 | 15 | |
| Max. flow (L/min) | cont. | 40 | 50 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
| int. | 45 | 60 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | |
| Weight (kg) | 6.5 | 6.7 | 6.9 | 7 | 7.3 | 7.6 | 8 | 8.5 | 9 | 9.5 | |
Hydraulic service and hydraulic sales are an important part of the hydraulic market. They provide convenience to hydraulic users, save costs and improve work efficiency.
There are many companies in the two types of hydraulic service and hydraulic sales that focus on hydraulic motors for sale, because hydraulic motors have been used more and more in hydraulic machinery in the past 20 years.
According to HANJIU, it is speculated that hydraulic motors will have a huge market in the future agricultural machinery, earthmoving machinery, construction machinery, animal husbandry machinery and other machinery.
In the future, hydraulic motors for sale will be a very important position in the hydraulic industry. HANJIU hereby promises to strongly support hydraulic motors for sale companies, with free technology and humane after-sales service, to make profits for sales companies.
The above good policies don't have to worry about your country and skin color, don't worry about your faith and church, HANJIU will provide brotherhood reception and support.
Let's work together to make the hydraulic battlefield simple, friendly, and pure. Only when the world is at peace and people live and work in peace and contentment can we do our best work.
