Product Details:
Payment & Shipping Terms:
|
| Type: | Hydraulic Drive Motor | Speed: | Cont160rpm/int.195rpm |
|---|---|---|---|
| Warranty: | 1year | Torque: | Cont.1085/int.1180 N.m |
| Output: | 14.5kw-16.5kw | Pressure: | 17.5mpa-19mpa |
| High Light: | re26180200 white hydraulic motors,roller stator white hydraulic motors,re26180200 danfoss hydraulic motor |
||
Product details:
| 1, | model number | BMER |
| 2, | displacement | 475ml/r |
| 3, | flange | magneto Mount |
| 4, | shaft | SAE 6B |
| 5, | oil port | 7/8-14 o-ring |
| 6, | drain | --- |
| 7, | rotation | Standard |
| 8, | paint | Black |
| 9, | replace | white RE |
| Type |
BMER 125 |
BMER 160 |
BMER 200 |
BMER 230 |
BMER 250 |
BMER 300 |
BMER 350 |
BMER 375 |
BMER 475 |
BMER 540 |
BMER 750 |
|
|
Geometric displacement (cm3 /rev.) |
118 | 156 | 196 | 228 | 257 | 296 | 345 | 371 | 462 | 540 | 745 | |
| Max. speed (rpm) | cont. | 360 | 375 | 330 | 290 | 290 | 250 | 220 | 200 | 160 | 140 | 100 |
| int. | 490 | 470 | 425 | 365 | 350 | 315 | 270 | 240 | 195 | 170 | 120 | |
| Max. torque (N*m) | cont. | 325 | 450 | 530 | 625 | 700 | 810 | 905 | 990 | 1085 | 980 | 1050 |
| int. | 380 | 525 | 600 | 710 | 790 | 930 | 1035 | 1140 | 1180 | 1240 | 1180 | |
| peak | 450 | 590 | 750 | 870 | 980 | 1120 | 1285 | 1360 | 1260 | 1380 | 1370 | |
| Max. output (kW) | cont. | 12.0 | 15 | 15.5 | 16.0 | 17.5 | 18.0 | 17.5 | 16.5 | 14.5 | 11.5 | 8.0 |
| int. | 14.0 | 17.5 | 18.0 | 19.0 | 20.0 | 21.0 | 20.0 | 19.0 | 16.5 | 15.0 | 10.0 | |
| Max. pressure drop (MPa) | cont. | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 17.5 | 14 | 10.5 |
| int. | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 19 | 17.5 | 12 | |
| peak | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 27.6 | 20.5 | 20.5 | 14 | |
| Max. flow (L/min) | cont. | 45 | 60 | 70 | 70 | 75 | 80 | 80 | 75 | 75 | 75 | 75 |
| int. | 60 | 75 | 85 | 85 | 90 | 95 | 95 | 90 | 90 | 90 | 90 | |
Other types
RE18070400
RE24070300
RE26080410
RE18070310
Low Speed High Torque (LSHT) hydraulic motors orbit type motors that interchange with Parker hydraulic motors, Danfoss hydraulic motors, White Drive Products hydraulic motors, TRW Ross hydraulic motors and Eaton Char-Lynn hydraulic motors. Honor Pumps high speed, low torque hydraulic gear motors that interchange with Barnes Contcentric hydraulic motors. Anfield Industries hydraulic motors.
All hydraulic motors that are promoted as a "Drop in replacement for" meet or exceed the specifications of the the hydraulic motor that they are replacing. These hydraulic motors are a direct replacement for fit, form and function. All hydraulic motors that HANJIU Technology Supply offer have a 12 month warranty from date of shipment.
