Product Details:
Payment & Shipping Terms:
|
| Item: | LSHT Motor | OEM #: | TB0065FS100AAAA |
|---|---|---|---|
| Manufacturer: | Hanjiu | Displacement: | 65 Ml/r |
| Mounting Flange: | 4 Bolt | Shaft Type: | 1'' Woodruff Key Shaft |
| High Light: | 1800psi Lsht Hydraulic Motor,Medium Duty Lsht Hydraulic Motor,1800psi hydraulic motor high torque |
||
TB0065FS100AAAA, Hydraulic Motor: TB, 4-Bolt, 511 RPM Max. RPM, 1800 psi Quick review: This is Parker compatible motor with same form, fit and function This medium duty small frame motor incorporates many features that are included in heavy duty motors. Design features include a high pressure shaft seal so external drains are never required, roller vane technology for automatic wear compensation and full flow internal cooling and flushing. This is a very economical motor for most medium duty applications. Here is main specifications: More PARKER Low speed high torque compatible motors availalbe like : TB From China, Hanjiu produce variety of low speed high toqrue hydraulic motors to suit range of brands & applications, in more competitive way. We introduce us as advantage supplement of your current hydraulic supply, solve reliability, quality, time, cost, brand promotion. Contact us to talk work together.
Specifications
Shaft:
1" Keyed
Rotation:
Standard
Displacement (cm3/rev):
65
Mounting:
4 Bolt with 3/8"-16 UNC
Ports:
7/8-14 SAE
Geometric Displacement:
65 cm3/rev (4.0 in3/rev)
Maximum Speed:
511 rev/min
Maximum Torque - Continuous / Intermittent:
107 Nm (946 lb in) / 145 Nm (1284 lb in)
TC
TJ
TE
TF
TG
TK
