2 Bolts Flange Motor BMR500 Hydraulic Orbit Motor 25mm Key Shaft G1/2 BSPP Side Ports

Name: 2 Bolts Flange Motor BMR500 Hydraulic Orbit Motor 25mm Key Shaft G1/2 BSPP Side Ports
Brand: Hanjiu
SKU: BMR500
Rating: 4.7 (100 reviews)

Large Image : 2 Bolts Flange Motor BMR500 Hydraulic Orbit Motor 25mm Key Shaft G1/2 BSPP Side Ports

Product Details:

Place of Origin:	China
Brand Name:	Hanjiu
Certification:	ISO9001:2015
Model Number:	BMR500

Payment & Shipping Terms:

Minimum Order Quantity:	50 units
Price:	Negotiable
Packaging Details:	Carton packing , with a tray or wooden box if needed .
Delivery Time:	10-15 working days
Payment Terms:	T/T, Western Union,Paypal .
Supply Ability:	100,000 units / Year

Contact Now

Detailed Product Description

Product Name:	Hydraulic Orbital Motors	Displacement:	500CC
Applications:	Sweepers, Road Sweepers,trenchers	Replacement:	Hanjiu BMR = OMR, Eaton S,T Series , M+S MR Etc
Ports Size:	G1/2	Shaft:	25mm Key Shaft
High Light:	BMR500 hydraulic orbit motor , BSPP hydraulic orbit motor

2 bolts flange motor BMR500 hydraulic orbit motor,25mm key shaft, G1/2 BSPP side ports

Product details:

product type	BMR 500 spool valve motor
displacement	500cc
flange	2-φ13.5 Rhomb-flange pilot φ82.5x8
shaft	25mm key shaft
oil ports	G1/2 manifold mount 4-M8,G1/4

Main Specifications:

Technical data for BMR with 25 and 1 in and 1 in splined and 28.56 tapered shaft:

Type		BMR BMRS 36	BMR BMRS 50	BMR BMRS 80	BMR BMRS 100	BMR BMRS 125	BMR BMRS 160	BMR BMRS 200	BMR BMRS 250	BMR BMRS 315	BMR BMRS 375
Geometric displacement (cm3/rev.)		36	51.7	81.5	102	127.2	157.2	194.5	253.3	317.5	381.4
Max. speed (rpm)	cont.	1085	960	750	600	475	378	310	240	190	155
Max. speed (rpm)	int.	1220	1150	940	750	600	475	385	300	240	190
Max. torque (N·m)	cont.	72	100	195	240	300	360	360	390	390	365
	int.	83	126	220	280	340	430	440	490	535	495
	peak	105	165	270	320	370	460	560	640	650	680
Max. output (kW)	cont.	8.5	9.5	12.5	13	12.5	12.5	10	7	6	5
Max. output (kW)	int.	9.8	11.2	15	15	14.5	14	13	9.5	9	8
Max. pressure drop (MPa)	cont.	14	14	17.5	17.5	17.5	16.5	13	11	9	7
	int.	16.5	17.5	20	20	20	20	17.5	15	13	10
	peak	22.5	22.5	22.5	22.5	22.5	22.5	22.5	20	17.5	15
Max. flow (L/min)	cont.	40	50	60	60	60	60	60	60	60	60
Max. flow (L/min)	int.	45	60	75	75	75	75	75	75	75	75
Weight (kg)		6.5	6.7	6.9	7	7.3	7.6	8	8.5	9	9.5

2 Bolts Flange Motor BMR500 Hydraulic Orbit Motor 25mm Key Shaft G1/2 BSPP Side Ports 0

2 Bolts Flange Motor BMR500 Hydraulic Orbit Motor 25mm Key Shaft G1/2 BSPP Side Ports 3

2 Bolts Flange Motor BMR500 Hydraulic Orbit Motor 25mm Key Shaft G1/2 BSPP Side Ports 4

Hanjiu Technology is a world leader within production of low speed orbital motors with high torque.

We can offer more than 3000 different orbital motors, categorized in types, variants and sizes (including different shaft

versions).

The motors size vary (rated displacement) from 8 to 800 cm3 [0.50 to 48.9 in3 ] per revolution.

• Small sized motors:

‒ BMM

• Medium sized motors:

‒ BMP, BMR and BMH

--BM2, OK

‒ BMP X and BMR X

‒ BMPH and BMRS

‒ BMRWN

• Large sized motors:

‒ BMS, BMT and BMV

---BMK2,BMK6,BMK4,BMK10

---BMER-2,BMER-3,BMER-4
