Product Details:
Payment & Shipping Terms:
|
| Features: | Eaton Replacement | Item: | Disc Vlave & Spool Valve Motors |
|---|---|---|---|
| Type: | Disc Geroler Standard | Series: | 109-1185-006 |
| Manufactuerer: | Hanjiu | Origin: | China |
| High Light: | Hydraulic Eaton Geroler Motor,Hydraulic Geroler Motor Replacement,109-1185-006 Eaton Geroler Motor |
||
Quick review:
Outline form, installation size and working function are the same as Eaton char-lynn, save your cost
109-1185-006
M04080AF11AC0300000000000AA00F
Manufacturer: Hanjiu
Specifications:
Displacement: 130.3 cm³/rev
Mounting: 4 BOLT; 127.00 PILOT DIA.14.27 DIA. HOLES ON 161.92 DIA. BOLT CIRCLE
Shaft: 40.00 DIA. STRAIGHT
Ports: G 3/4 PORTS
Flow: G 1/4
Maximum Speed:722 rpm
Torque:375 Nm
More Eaton Char-Lynn Hydraulic motor 4000 series replacement
| 109-1001-006 | 109-1212-006 |
| 109-1003-006 | 109-1215-006 |
| 109-1052-006 | 109-1233-006 |
| 109-1100-006 | 109-1234-006 |
| 109-1101-006 | 109-1236-006 |
| 109-1102-006 | 109-1238-006 |
| 109-1103-006 | 109-1245-006 |
| 109-1104-006 | 109-1246-006 |
| 109-1105-00 | 109-1264-006 |
| 109-1106-006 | 109-1363-006 |
| 109-1114-006 | 109-1450-006 |
| 109-1115-006 | 109-1453-006 |
| 109-1116-006 | 109-1173-006 |
| 109-1117-006 | 109-1543-006 |
| 109-1119-006 | 110-1092-006 |
| 109-1158-006 | 110-1093-006 |
